Side View of Osprey Boulder (Lower)
This image shows a side-view of the lower portion of the largest boulder in the crater where sample site Osprey is located. The crater is near asteroid Bennu’s equator, and the sample site itself is located below the boulder and directly to the right of the patch of dark material. The image was taken by the PolyCam camera on NASA’s OSIRIS-REx spacecraft on February 11 from a distance of 0.4 miles (0.6 km). The field of view is 32 ft (9.6 m). For reference, the small, bright rock (just below the tip of the large boulder) is 4 inches (10 cm), which is about the size of a grapefruit. The image was obtained during the mission’s Reconnaissance B phase. When the image was taken, the spacecraft was over the northern hemisphere, pointing PolyCam north and to the east. This oblique observation angle reveals another side of the boulder, which usually appears as a flat, spear-tip shape in images. During this flyover, the OLA instrument was scheduled to provide ranging data to PolyCam in order to focus the camera. However, due to an anomaly that occurred with OLA, the PolyCam images from this flyover are slightly out of focus.
The small, horizontal streaks on the bottom left of the image are caused by short exposure times (less than three milliseconds). Short exposure times are required for imaging areas near Bennu’s equator, since they are brightly illuminated by the sun. The duration between images is so short that the imaging system does not always have time to process all the data generated by the previous exposure, which results in icicle-like patterns.
Date Taken: Feb 11, 2020
Instrument Used: OCAMS (PolyCam)
Credit: NASA/Goddard/University of Arizona
